MakerFocus Wireless Tracker Integrate UC6580 SX1262 863 923MHz LoRa WiFi Bluetooth ESP32 Development Board with Display for Arduino Intelligent Scene
MakerFocus Wireless Tracker Integrate UC6580 SX1262 863 923MHz LoRa WiFi Bluetooth ESP32 Development Board with Display for Arduino Intelligent Scene
WirelessTracker is a development kit based on ESP32-S3FN8. It combines the SX1262 and LC6580 to provide a fast GNSS solution for the Internet of Things.
It can track any object and then upload data wirelessly via WI-FI, Bluetooth, LORA.
The wireless tracker supports L1+L5/L2, and supports multi-system joint positioning of GPS, GLONASS, BDS, GALILEO, NAVIC, and QZSS.
Features:
1.ESP32-S3FN8+SX1262+UC6580 chip, supports WI-FI, LORA, BLUETOOTH, GNSS
2. Dual-band multi-system low-power design based on 22nm technology
3. Support L1+L5/L2, support GPS, GLONASS, BDS, Galileo, NAVIC, QZSS multi-system joint positioning
4.Type-CUSB interface comes with complete voltage regulator, ESD protection, circuit protection, radio frequency shielding and other protection measures
5. Onboard SH1.25-2 battery interface, integrated lithium battery management system (charge and discharge management, overcharge protection, battery power
detection, USB/battery powered automatic switching)
6 Onboard Wi-Fi, Bluetooth-specific 2.4GHZ metal spring antenna, reserved IPEX (u./D) interface for LoRa and GNSS use
7. Onboard 0.96-inch80(H)*160(V) dot matrix TFT-LCD display, which can be used to display debugging information, battery power, etc.
8.Support Arduino development environment.
Specification:
LoRa chip: ESP32-S3FN8
GNSS chip: SX1262
Maximum output power: 21+1dBm
Receive sensitivity: -139dBm
Battery: 3.7v lithium battery power supply interface
Operating temperature:-20 - 70°C
Size: 85.48x28.06x13.52mm
Wi-Fi: 802.11b/g/n,upto150Mbps
Bluetooth: BluetoothLE：Bluetooth5,Bluetoothmesh
Package Included:
1X Wireless Tracker
